stainless steel parallel tubes

applicable models	format	material	outer diameter	material thickness
forced to exhaust	380-600mm	sus 201/304	φ5090-6090-50100-60100	0.3mm

details>>

stainless steel exhaust pipe

applicable models	format	material	outer diameter	material thickness
forced to exhaust	φ50(φ60/φ70)*380-600mm	sus 201/304	φ50-60-70	0.3mm

details>>

aluminum tubes with connectors bring out the smoke tube

applicable models	format	material	outer diameter	material thickness
forced to exhaust	1-5m	sus 201/304	φ50-60-100-110-120-130	0.1mm

details>>

exhaust tubes

applicable models	format	material	outer diameter	material thickness
forced to exhaust	1-5m	sus 201/304	φ50-φ60-φ70-φ90-φ110-φ120-φ130	0.1mm

details>>

the tubes extended period (with connector)

applicable models	format	material	outer diameter	material thickness
forced to exhaust	1-5m	sus 201/304	φ50-60-100-110-120-130	0.1mm

details>>

back exhaust pipe

applicable models	format	material	outer diameter	material thickness
forced to exhaust	φ110φ50555	sus 201/304	φ110*50	0.3mm

details>>

stainless steel parallel tubes

details>>

the secondary condensate heat exchanger lnq-a (sus304 #)

(1)the overall structure of the components of 304 # stainless steel material, attractive appearance and corrosion resistance;
(2)the internal coil choice of ø20 stainless steel bellows, to ensure thermal conversion rate while increasing the water flow machine thermal efficiency of 15-20%;
(3)the inlet and outlet with bellows using high-frequency welding process, can withstand a 1.5-2.0mpa water pressure and no leakage and abnormal noise;

parallel pipe joints series

applicable models	format	material	outer diameter	material thickness
forced to exhaust	5000-1000mm	sus 201	φ9050/φ9050/φ110*60	0.3mm

details>>
